Dimensions: 165 x 268.1 x 31.8 mm (6.50 x 10.56 x 1.25")
Weight: 1.3 kg (2.87 lb)
Interfaces:
Networking (4) 100/1000 Mbps and 2.5/5/10G RJ45 Ports (2) 1/10G SFP+ Ethernet Ports
Management: Ethernet In-Band (1) RJ45 Serial Port Out-of-Band (1) USB Type C Port Out-of-Band
Power Method: 54VDC, 3.88A Power Adapter (Included) or DC Input with Terminal Block
Power Supply: External AC/DC Adapter (Included) or DC Power Source
Supported Voltage Range: 44 to 57VDC
Max. Power Consumption (Excluding PoE Output): 40W
LEDs System: Status
PoE; Speed/Link/Activity
Link/Activity
ESD/EMP Protection: Air: ± 18 kV, Contact: ± 12 kV
Shock and Vibration: ETSI300-019-1.4 Standard
Operating Temperature: -5 to 45° C (23 to 113° F)
Operating Humidity: 5 to 95% Non-condensing
Certifications: CE, FCC, IC
PoE
PoE Interfaces: PoE++ IEEE 802.3bt (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-)
Max. 802.3bt Wattage per Port by PSE: 60W
Voltage Range 802.3af Mode: 44-57V
Voltage Range 802.3at/bt Mode: 50-57V
